Today, we would like to give a brief introduction to set screws (also known as grub screws).



In our previous article, we discussed 「Melamine Decorative Boards」.



This time, we will introduce another material that is commonly used in interior construction projects.



If you would like to learn more about board installation work itself, please check out 「Board Installation Work」 as well.



What Is a Set Screw?









First, let’s take a brief look at what a set screw is.



A set screw, also known as a grub screw, is a type of screw used to secure one component to another without the need for a nut.



Other common names include:



• Set Screw
• Grub Screw
• Hex Socket Set Screw



Typical applications include:



• Securing gears, pulleys, and sprockets to a shaft
• Fixing handles and knobs in place
• Preventing machine components from moving during operation



Unlike ordinary screws, set screws are typically installed flush with or below the surface of the material, making them ideal for applications where a smooth finish is required.



Set screws are available in a variety of shapes and sizes, each designed for different applications and performance requirements.



Although they are small and often overlooked, set screws play an essential role in many machines, tools, and industrial products. They are one of the key components that help keep mechanical parts securely in place.







Types and Features of Set Screws



Set screws are available in a variety of designs. Generally, there are five common tip styles and four common drive types (head socket shapes).



The tip shape affects how the screw grips and secures a component, while the drive type determines which tool is used for installation and removal.



Different designs are suitable for different applications, so selecting the appropriate type is important for achieving reliable performance.



First, let’s take a look at the five common tip styles of set screws.





Tip Styles



Cup Point









The cup point is one of the most common tip styles used for set screws. As its name suggests, the tip has a small concave recess that helps provide a secure grip on the mating surface.



This is the most widely used type of set screw tip and is often considered the standard design for general applications. In many cases, when people refer to a set screw, they are referring to a cup point set screw.



Because of its strong holding power and versatility, it is commonly used in machinery, equipment, and various industrial applications.







Flat Point











A flat point set screw has a flat tip at the end of the threaded section.



Because the tip is flat, it is suitable for applications where repeated adjustments or removal may be required. It is also commonly used when it is important to avoid damaging the surface of the component being secured.



Compared with other tip styles, the flat point provides a firm hold while minimizing surface damage, making it a popular choice for delicate or frequently adjusted applications.







Cone Point









A cone point set screw has a sharp, pointed tip, as its name suggests.



Unlike a flat point set screw, a cone point is designed for permanent or long-term fastening applications where a strong holding force is required.



The pointed tip digs into the surface of the mating material, creating a secure connection. Because it leaves an indentation in the material, it is generally not suitable for applications that require frequent adjustments or repeated assembly and disassembly.







Dog Point









A dog point set screw features a reduced-diameter tip that extends beyond the threaded section.



Although the tip is flat, its contact area is smaller than that of a flat point set screw. This design allows the tip to fit into a pre-drilled hole or slot, making it useful for locating and securing components with precision.



Dog point set screws are often used in applications where accurate positioning is required. In some cases, the extended tip can also serve as a locating pin or key, helping to maintain alignment between connected parts.







Double Point









A double point set screw features a unique tip design with two contact points and a sharp center projection located within a recessed tip.



This design provides a strong and secure grip, making it suitable for fastening and positioning mechanical components.



Because of its shape, a double point set screw offers excellent resistance to loosening, reliable penetration into the mating material, and improved stability against vibration and movement.



For these reasons, it is often used in machinery and equipment where accurate positioning and secure fastening are required.







Drive Types (Head Socket Shapes)





Next, let’s look at four common drive types used for set screws.





Phillips Drive









A Phillips drive features a cross-shaped recess in the screw head.



This design is intended for use with a Phillips screwdriver, allowing the driver and screw to engage securely for accurate and stable tightening.



Although the design is relatively simple, manufacturing Phillips screws requires specialized production processes and equipment.



Phillips drive screws are widely used in many applications, including electronic devices, household products, and automobiles.







Hex Socket Drive







A hex socket drive features a hexagonal recess in the head of the screw.



This is one of the most commonly used drive types for set screws. It is designed to be tightened and loosened using a hex key (Allen wrench) or hex driver.



Because of its hexagonal shape, it can transmit higher torque than many other drive types, making it suitable for applications that require a strong and secure fastening force.



Like the cup point tip style, the hex socket drive is widely used in general applications. In many cases, when people refer to a standard set screw, they are referring to a hex socket set screw.



Hex socket set screws are commonly found in machinery, industrial equipment, and automotive applications.







Slotted Drive











A slotted drive features a single straight slot cut into the head of the screw.



This is one of the oldest and most traditional screw drive designs. A flat-head screwdriver is inserted into the slot to tighten or loosen the screw.



The slotted design allows the screwdriver to engage with the screw head and transmit torque effectively. Although it is a simple design, it remains widely used in various applications.



Slotted screws are commonly found in woodworking projects, door hinges, furniture assembly, and other general-purpose applications.



Because of their classic appearance, they are often used in traditional furniture, restoration work, and DIY projects.









Torx Drive









A Torx drive features a distinctive six-point star-shaped recess in the head of the screw.



One of the main advantages of the Torx design is its ability to transmit higher torque with less friction than many conventional drive types. The design also reduces the risk of cam-out, helping to prevent wear and damage to both the screw and the driving tool.



Because the driving angle is small and force is distributed more evenly, Torx screws can withstand high tightening forces while maintaining durability and reliability.



Torx screws require specialized tools such as Torx screwdrivers or Torx wrenches for installation and removal.



Today, Torx drives are widely used across many industries, including automotive, machinery, electronics, and security-related applications where high torque and reliability are essential.









Price Range of Set Screws





Next, let’s take a brief look at the typical price range of set screws.



The price of a set screw can vary depending on several factors, including:



• Type
• Brand
• Size
• Supplier or retailer
• Geographic region



Because these factors can significantly affect pricing, the cost of set screws may vary from one product to another.



The following information provides a general overview of typical price ranges and purchasing considerations.







Standard Set Screws for General Applications

Standard set screws are commonly sold in small boxes or bulk packs, and prices vary depending on the size, material, and quantity purchased.



For general-purpose applications, a pack of 100 set screws typically starts at a relatively low cost, making them an affordable fastening solution for a wide range of projects.







High-Strength and Specialty Material Set Screws



Set screws made from stainless steel, high-strength alloys, or other specialty materials are generally more expensive than standard products.



In addition, special surface treatments and coatings can increase the price. Examples include corrosion-resistant finishes, heat-resistant coatings, and other protective treatments designed for demanding environments.



Depending on the material and performance requirements, prices can range from a few cents to several dollars per screw.





Security and Specialized Applications



Set screws designed for security purposes or specialized industrial applications are often more expensive than standard models.



These products may feature unique drive types, tamper-resistant designs, or specialized materials to meet specific requirements.



Because of their advanced features, the cost per screw can be significantly higher than that of standard set screws.





Premium Brand Products



Set screws manufactured by well-known tool and fastener brands are often priced higher than generic alternatives.



Although premium products typically cost more, they are valued for their consistent quality, reliability, and manufacturing precision.



For critical applications, many users prefer trusted brands despite the higher cost.





Size



The size of a set screw is another important factor that affects pricing.



In general, larger screw diameters and longer lengths require more material and manufacturing resources, resulting in higher costs.



When selecting a set screw, it is important to consider not only the price but also the size and specifications required for the intended application.







Set Screw Size Chart







Nominal Size	Thread Diameter	Hex Key Size
M3	3mm	2mm
M4	4mm	2.5mm
M5	5mm	3mm
M6	6mm	4mm
M8	8mm	5mm
M10	10mm	6mm
M12	12mm	8mm









Prices may also vary depending on the retailer, supplier, and geographic region. Therefore, it is recommended to compare products from multiple sources before making a purchase.



Some suppliers sell set screws individually, while others offer them in bulk packages or cases.



In general, the price range of set screws can vary significantly depending on the quantity purchased, material, size, and product specifications.



To find the best value, it is a good idea to compare products from multiple manufacturers and suppliers while considering both quality and budget requirements.



Selecting the right set screw is not only a matter of price but also of choosing a product that meets the performance and reliability needs of the intended application.













Summary



In this article, we provided a brief introduction to set screws and their various types and applications.



Although small in size, set screws play an important role in interior construction, manufacturing, and building projects. They are commonly used to secure handles, mechanical components, and other parts in place.



Set screws can be found in a wide range of applications, including kitchens, bathrooms, furniture, commercial facilities, schools, offices, industrial equipment, and DIY projects. While they often go unnoticed, they are essential components that help ensure safety, stability, and reliability.
